Overview of
Production FlowOverview of Production Flow
Production Flow is a web application that allows you to monitor and manage the print files uploaded to Epson Cloud Solution PORT (cloud).
Production Flow includes the following main functions.
Process management
You can manage all tasks from submission to shipping. You can register routine tasks before and after the printing process,
such as design, pretreatment agent application, laminating, cutting, and manage their progress.
Work order management
Print files are managed in units called work orders. You can use work orders to manage information such as print files, number
of copies to print, delivery time, and customers.
Printing process management
Uploaded print files are printed using software (digital front end) that sends print data from the cloud to printers. When
making settings for print instructions, you can allocate the print file to multiple printers or a printer at the remote location.
You can also specify a spot color contained in the PDF file and match the printed color to the sample color before the actual
printing (requires an Epson spectrophotometer).
Printer monitoring
Production Flow constantly monitors the printers registered in Epson Cloud Solution PORT. You can check the status and printing progress of each printer.
Functions Using Epson Edge Print (RIP)
-
Remote Printing Function
Epson Edge Print allows you to print on a remote printer using the print settings made by the sender. You do not need to redo the print settings
for the destination printer.
-
Print Job Allocation Function
You can allocate print jobs to multiple printers suitable for printing and print them all at once.
