Details of the Batch Delete Screen

This is displayed when you click the Batch Delete button on the Task chart screen.

The list of print files at the time you clicked the Batch Delete button is displayed.

Item		Description
A	Work order display switching button (Incomplete / Complete)	Displays the work orders selected on the Task chart screen. You cannot switch between Incomplete and Complete.
B	Selected	Displays the number of selected print files.
C	Search bar	When you enter any keyword, a list of work order names that partially match the keyword is displayed.
D	Include today's complete orders	This is displayed in the same state as on the Task chart screen. You cannot change the state.
E	Checkbox	Select the print files you want to delete. Any selections you have made are cleared when you perform a search or navigate to another page. You can select or deselect all print files on the displayed page with the checkbox next to Work order name.
F	Work order name	Displays the work order name and status of the print file at the time the Batch Delete button is clicked.
G	Delivery time	Displays the delivery time set for the work order.
H	File name	Displays the print file name.
I	Delivery quantity	Displays the total number of copies to print the print file.
J	Notes	Displays the notes set for the print file.
K		Up to 500 work orders can be displayed on one page. If this number is exceeded, a new page is added automatically. Click the page number icon to view that page. Click or to display the previous page or the next page.
L	Delete	Click to display the confirmation screen and delete the selected print files from the work order. If you delete all of the print files in the work order, the work order is deleted as well.
M	Cancel	Click to cancel the batch deletion and return to the Task chart screen.
